Luna Series LED flexible strip are our middle power (10-20W) range which is widely used in commercial project. Luna used advanced technique which can enhance the brightness especially on the upgraded SMD2835 LEDs compare to our Zodiac Series. At the same time, you will see higher LED density like 180LEDs and 240LEDs in the Luna Series which will not only brings more lumen output but also more smooth and uniform light distribution.
| LED Type | SMD2835 |
| LED Quantity | 120 LEDs Per Meter |
| CRI | ≥90 |
| Color Temperature | 2700K / 3000K / 4000K / 6500K |
| Voltage | 12 VDC / 24VDC |
| Wattage | 19.2W/M |
| Efficiency | 90LM/W |
| Max Lumen @ 4000K | 1790LM/M |
| PCB Width | 12MM |
| Copper Quantity | 3Oz. |
| Cutting Length | 25MM @ 12V 50MM @ 24V |
| IP Rating | IP67 |
| Beam Angle | 120 Degree |
| Temperature, Operating, Minimum | -35℃ |
| Temperature, Operating, Maximum | 60℃ |
| Maximum Recommended Length | 5 Meters |
| Lifetime | 50,000 Hours |
| Certification | UL-E464546, CE, RoHS, FCC, C-tick |
| Warranty | 5 Years |
| Adhesion | TESA 4965 / 3M Back Tape |
