Iris Series are your best choice for color and multi-color LED products like RGB, RGBW and even RGB+VW. Thousands of color combination you could imagine can be achieved in the Iris Series. Besides these traditional multi-color strips, we also present popular AI (artificial intelligent) RGB and RGBW strips which could be widely used for various entertainment venues like pub, shopping mall and holiday decoration.
LED Type
SMD5060 5 IN 1
LED Quantity
60 LEDs Per Meter
CRI
≥90 for white
Color Temperature
RGB +2700K + 6500K
Voltage
24 VDC
Wattage
24 W/M
Efficiency
55LM/W
Max Lumen @ 4000K
1332 LM/M
PCB Width
12MM
Copper Quantity
3 Oz.
Cutting Length
100MM @ 24V
IP Rating
IP43 / IP65 / IP66 / IP67 / IP68 / IPnano
Beam Angle
120 Degree
Temperature, Operating, Minimum
-35℃
Temperature, Operating, Maximum
60 ℃
Maximum Recommended Length
5 Meters
Lifetime
50,000 Hours
Certification
UL-E464546, CE, RoHS, FCC, C-tick
Warranty
3 Years
Adhesion
TESA 4965 / 3M Back Tape
Iris Series are your best choice for color and multi-color LED products like RGB, RGBW and even RGB+VW. Thousands of color combination you could imagine can be achieved in the Iris Series. Besides these traditional multi-color strips, we also present popular AI (artificial intelligent) RGB and RGBW strips which could be widely used for various entertainment venues like pub, shopping mall and holiday decoration.
