SMD1210 30LEDs 2.4W Music 16.5ft Home Led Strip Light

  • OL-1210FH-8mm2.4W-3024-W
CCT:
Voltage:
IP Rating:
Availability:

Zodiac Series are our low power (<10W/M) product version and economic solution for your choice in retail area and for furniture lighting, you can find flexible strip designed for both indoor and outdoor application for example, IP68 which is silicone tube with silicone filling inside. You can also find single color like ordinary red, green and blue which could be for garden decoration.


LED   TypeSMD1210
LED Quantity30   LEDs / Meter
CRI≥90
Color Temperature2700K  3000K    4000K  6500K
Voltage24   VDC/12 VDC
Wattage2.4   W / Meter
Efficiency86LM/W
Max Lumen @ 4000K211   LM/M
PCB Width8MM
Copper Quantity2   Oz.
Cutting Length100MM   @ 12V
166.6MM @ 24V
IP RatingIP43/IP65/IP66/IP67/IP68/IPnano
Beam Angle120   Degree
Temperature, Operating, Minimum-35℃
Temperature, Operating, Maximum60   ℃
Maximum Recommended Length5   Meters
Lifetime50,000   Hours
CertificationUL   - E464546, CE, RoHS, FCC, C-tick
Warranty5   Years
AdhesionTESA   4965 / 3M Back Tape


Dimension
