SMD2835 tooth Led Strip Light

  • OL-2835FHW7-10mm7.2W-3024-W
CCT:
Voltage:
IP Rating:
Availability:

Zodiac Series are our low power (<10W/M) product version and economic solution for your choice in retail area and for furniture lighting, you can find flexible strip designed for both indoor and outdoor application for example, IP68 which is silicone tube with silicone filling inside. You can also find single color like ordinary red, green and blue which could be for garden decoration.


LED TypeSMD2835
LED Quantity30LEDs Per Meter
CRI≥90
Color Temperature2700K / 3000K / 4000K / 6500K
Voltage12VDC / 24VDC
Wattage7.2 W/M
Efficiency80LM/W
Max Lumen @ 4000K571LM/M
PCB Width10MM
Copper Quantity2  Oz.
Cutting Length100MM   @ 12V
166.6MM @ 24V
IP RatingIP67
Beam Angle120 Degree
Temperature Operating Minimum-35℃
Temperature Operating Maximum60℃
Maximum Recommended Length5 Meters
Lifetime50,000 Hours
CertificationUL-E464546, CE, RoHS, FCC, C-tick
Warranty5 Years
AdhesionTESA 4965 / 3M Back Tape


Dimension
