SMD3014 60LEDs 4.8W Side View Led Strip Light

  • OL-3014FSV-8mm4.8W-6024-W
CCT:
Voltage:
IP Rating:
Availability:

Zodiac Series are our low power (<10W/M) product version and economic solution for your choice in retail area and for furniture lighting, you can find flexible strip designed for both indoor and outdoor application for example, IP68 which is silicone tube with silicone filling inside. You can also find single color like ordinary red, green and blue which could be for garden decoration.


LED TypeSide Emitting SMD3014
LED Quantity60LEDs Per Meter
CRI≥80
Color Temperature2700K / 3000K / 4000K / 6500K
Voltage12VDC / 24VDC
Wattage4.8W/M
Efficiency71LM/W
Max Lumen @ 4000K372LM/M
PCB Width8MM
Copper Quantity2Oz.
Cutting Length

50MM   @ 12V

100MM @ 24V

IP RatingIP43 / IP66 / IP68 / IPnano
Beam Angle120Degree
Temperature Operating Minimum-35℃
Temperature Operating Maximum60℃
Maximum Recommended Length5 Meters
Lifetime50,000 Hours
CertificationUL-E464546, CE, RoHS, FCC, C-tick
Warranty5Years
AdhesionTESA 4965 / 3M Back Tape


Dimension
