SMD5050 Waterproof Outdoor Led Strip Light

  • OL-5050FPW7-10mm23W-9624-RGB
Color:
Voltage:
IP Rating:
Availability:

Iris Series are your best choice for color and multi-color LED products like RGB, RGBW and even RGB+VW. Thousands of color combination you could imagine can be achieved in the Iris Series. Besides these traditional multi-color strips, we also present popular AI (artificial intelligent) RGB and RGBW strips which could be widely used for various entertainment venues like pub, shopping mall and holiday decoration.


LED   TypeSMD5050
LED Quantity96 LEDs Per Meter
CRI/
Color TemperatureRGB
Voltage24VDC
Wattage23W/M
Efficiency46LM/W
Max Lumen @ 4000K1060LM/M
PCB Width10MM
Copper Quantity3Oz.
Cutting Length62.5MM
IP RatingIP67
Beam Angle120 Degree
Temperature, Operating, Minimum-35℃
Temperature, Operating, Maximum60℃
Maximum Recommended Length5 Meters
Lifetime50,000 Hours
CertificationUL-E464546, CE, RoHS, FCC, C-tick
Warranty3 Years
AdhesionTESA 4965 / 3M Back Tape


Dimension
