Zodiac Series are our low power (<10W/M) product version and economic solution for your choice in retail area and for furniture lighting, you can find flexible strip designed for both indoor and outdoor application for example, IP68 which is silicone tube with silicone filling inside. You can also find single color like ordinary red, green and blue which could be for garden decoration.
LED Type
SMD2835
LED Quantity
60LEDs Per Meter
CRI
≥90
Color Temperature
2700K / 3000K / 4000K / 6500K
Voltage
24VDC
Wattage
7.2W/M
Efficiency
98LM/W
Max Lumen @ 4000K
730LM/M
PCB Width
12MM
Copper Quantity
3Oz.
Cutting Length
100MM
IP Rating
IP43 / IPnano
Beam Angle
120 Degree
Temperature Operating Minimum
-35℃
Temperature Operating Maximum
60℃
Maximum Recommended Length
20 Meters
Lifetime
50,000 Hours
Certification
UL-E464546, CE, RoHS, FCC, C-tick
Warranty
5 Years
Adhesion
TESA 4965 / 3M Back Tape
Zodiac Series are our low power (<10W/M) product version and economic solution for your choice in retail area and for furniture lighting, you can find flexible strip designed for both indoor and outdoor application for example, IP68 which is silicone tube with silicone filling inside. You can also find single color like ordinary red, green and blue which could be for garden decoration.
